| Designed for vehicles up to | EV Bus 10 -12 M |
| Cooling capacity | 34.9 kW / 119,000 Btu/h / 30,000 kcal/h |
| Evaporator air flow | 5400 m3/h |
| Condenser air flow | 11400 m3/h |
| Fresh air volume | 1200 m3/h |
| Dimension (l x w x h) | 3250× 1900×260 |
| Weight | 275 KGS |
| Power consumption (24V) | Max. 2.5 KW |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Blower motor | Speed by PWM centrifugal type |
| No. Of blower motor | 6 Pcs |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Fan motor | Speed by PWM axial type |
| No. Of fan motor | 6 Pcs |
| Brand | Panasonic |
| Input voltage range | 300~700V DC |
| Compressor power consumption (HV) | Max. 5 kW |
| Model | AC220V 3 Phrases 30~100HZ |
| Displacement | 74.4 cc |
| Compressor oil type | F68S |
| Compressor weight | 45 kg |
| PTC | Optional |
