| Designed for vehicles up to | Articulated EV Bus 18 M |
| Cooling capacity | 55.8 kW / 190,000 Btu/h / 48,000 kcal/h |
| Evaporator air flow | 4000 m3/h * 2 |
| Condenser air flow | 7600 m3/h * 2 |
| Fresh air volume | 1200 m3/h * 2 |
| Dimension (l x w x h) | 2670 x 1830 x 210 mm * 2 |
| Weight | 210 kg * 2 |
| Power consumption (24V) | Max. 1.5 KW * 2 |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Blower motor | Speed by PWM centrifugal type |
| No. Of blower motor | 4 Pcs * 2 |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Fan motor | Speed by PWM axial type |
| No. Of fan motor | 4 Pcs * 2 |
| Brand | Panasonic |
| Input voltage range | 300~700V DC |
| Compressor power consumption | Max. 5 kW * 2 |
| Model | AC220V 3 Phrases 30~100HZ |
| Displacement | 74.4 cc * 2 |
| Compressor oil type | F68S |
| Compressor weight | 45 kg * 2 |
| PTC | Optional |
