| Designed for vehicles up to | EV Bus 6 -7 M |
| Cooling capacity | 14 kW / 48,000 Btu/h / 12,000 kcal/h |
| Evaporator air flow | 3600 m3/h |
| Condenser air flow | 5700 m3/h |
| Fresh air volume | 1200 m3/h |
| Dimension (l x w x h) | 2600× 1635×245 mm |
| Weight | 190 kg |
| Power consumption (24V) | Max. 1.2 KW |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Blower motor | Brush type Speed by PWM |
| No. Of blower motor | 4 Pcs |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Fan motor | Brush type Speed by PWM |
| No. Of fan motor | 3 Pcs |
| Brand | HIGHLY |
| Input voltage range | 300~700V DC |
| Compressor power consumption (HV) | Max. 4 KW |
| Model | AC220V 3 Phrases 30~100HZ |
| Displacement | 34 cc |
| Compressor oil type | HAF68 |
| Compressor weight | 5 kg |
| PTC | Optional |
