| Designed for vehicles up to | EV Bus 8 -9 M |
| Cooling capacity | 27.9 kW / 96,000 Btu/h / 24,000 kcal/h |
| Evaporator air flow | 4000 m3/h |
| Condenser air flow | 760000 m3/h |
| Fresh air volume | 1250 m3/h |
| Dimension (l x w x h) | 2570× 1900×260 mm |
| Weight | 210 kg |
| Power consumption (24V) | Max. 1.5 KW |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Blower motor | Brush type Speed by PWM |
| No. Of blower motor | 4 Pcs |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Fan motor | Brush type Speed by PWM |
| No. Of fan motor | 4 Pcs |
| Brand | Panasonic |
| Input voltage range | 300~700V DC |
| Compressor power consumption (HV) | Max. 5 kW |
| Model | AC220V 3 Phrases 30~100HZ |
| Displacement | 74.4 cc |
| Compressor oil type | F68S |
| Compressor weight | 45 kg |
| PTC | Optional |
