| Designed for vehicles up to | 10-12 M |
| Cooling capacity | 37.2 kW / 127,000 Btu/h / 32,000 kcal/h |
| Evaporator air flow | 7000 m3/h |
| Condenser air flow | 9500 m3/h |
| Fresh air volume | 1750 m3/h |
| Dimension (l x w x h) | 3360 x 1720 x 244 mm |
| Weight (kg) | 170 kg |
| Power consumption (24V) | < 100 A |
| Max ambient temperature | 50 °C |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Blower motor | 3-Speed centrifugal type |
| No. Of blower motor | 6 Pcs |
| Type | Micro-channel heating exchanger |
| Fan motor | Axial type |
| No. Of fan motor | 5 Pcs |
| Brand | BOCK (BITZER/ VALEO) |
| Model | FK40 655 |
| Displacement | 650 cm³ |
| Compressor oil type | SE55 |
| Compressor weight | 41 kg (w/o clutch) |
| Alternator (Bosch/ Prestolite) | 150 A |
| Compressor bracket assy | Optional |
