| Designed for vehicles up to | 6 M |
| Cooling capacity | 12 kW / 41,000 Btu/h / 10,300 kcal/h |
| Evaporator air flow | 3200 m3/h |
| Condenser air flow | 4000 m3/h |
| Dimension (l x w x h) | 2200 x 1360 x 210 |
| Power consumption (12V) | 60 A |
| Max ambient temperature | 50 °C |
| Type | Hydrophilic aluminum foil with internal ridge aluminum tube |
| Blower motor | 3-Speed centrifugal type |
| No. Of blower motor | 4 Pcs |
| Type | Micro-channel heating exchanger |
| Fan motor | Axial type |
| No. Of fan motor | 2 Pcs |
| Brand | Valeo |
| Model | TM-21 |
| Displacement | 215 cm³ / rev |
| Compressor oil type | ZXL 100PG PAG OIL (180 cm³) |
| Compressor weight | 5.1 kg (w/o clutch) |
| Alternator (Bosch/ Prestolite) | Optional |
| Compressor bracket assembly | Optional |
