| Designed for vehicles up to | 14M- 15M Double-decker bus |
| Cooling capacity | 55.8 kW / 192,000 Btu/h / 48,000 kcal/h |
| Evaporator air flow | 3000 m3/h * 3 |
| Condenser air flow | 9500 m3/h |
| Power consumption (24V) | 150 A |
| Weight | 360 kg |
| Max ambient temperature | 50 °C |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Blower motor | 3-Speed centrifugal type |
| No. Of blower motor | 3 Pcs |
| Dimension (l x w x h) | 1504x 586x 261mm *1 & 1402.5.5x 387x201.5 mm * 2 |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Fan motor | Axial type |
| No. Of fan motor | 5 Pcs |
| Dimension (l x w x h) | 1951x 443x 352 mm |
| Brand | BOCK |
| Model | FK40 755 |
| Displacement | 755 cm³/rev |
| Compressor oil type | SE55 |
| Compressor weight | 31 kg (w/o clutch) |
| Alternator (Bosch/ Prestolite) | Optional |
| Compressor bracket assy | Optional |
