| Designed for vehicles up to | 8-9 M |
| Cooling capacity | 27.9 kW / 95,000 Btu/h / 24,000 kcal/h |
| Evaporator air flow | 4000 m3/h |
| Condenser air flow | 5700 m3/h |
| Fresh air volume | 1750 m3/h |
| Dimension (l x w x h) | 2670 x 1830 x 210 |
| Weight (kg) | 150kg |
| Power consumption (24V) | 65 A |
| Max ambient temperature | 50 °C |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Blower motor | 3-Speed centrifugal type |
| No. Of blower motor | 4 Pcs |
| Type | Micro-channel heating exchanger |
| Fan motor | Axial type |
| No. Of fan motor | 3 Pcs |
| Brand | Valeo |
| Model | TM-21 (TM-31 optional) |
| Displacement | 215 cm³/rev |
| Compressor oil type | ZXL 100PG PAG OIL (180 cm³) |
| Compressor weight | 5.1 kg (w/o clutch) |
| Alternator (Bosch/ Prestolite) | Optional |
| Compressor bracket assembly | Optional |
