| Designed for vehicles up to | 18 M Articulated bus |
| Cooling capacity | 65 kW / 222,000 Btu/h / 56,000 kcal/h |
| Evaporator air flow | 5400 m3/h *2 |
| Condenser air flow | 7600 m3/h *2 |
| Fresh air flow | 1350 m3/h |
| Dimension (l x w x h) | (3400× 1830 ×200) *2 |
| Weight | 200 kg |
| Power consumption (24V) | 85 A *2 |
| Max ambient temperature | 50 °C |
| Type | Hydrophilic aluminum foil with internal ridge copper tube |
| Blower motor | 3-Speed centrifugal type |
| No. Of blower motor | 6 Pcs *2 |
| Type | Micro-channel heating exchanger |
| Fan motor | Axial type |
| No. Of fan motor | 4 Pcs *2 |
| Brand | BOCK |
| Model | FK50 980 |
| Displacement | 976 cm³/rev |
| Compressor oil type | SE55 |
| Compressor weight | 42 kg (w/o clutch) |
| Alternator (Bosch/ Prestolite) | Optional |
| Compressor bracket assembly | Optional |
